name of product |
colour types |
product
standard |
usage and property |
industrial rubber sheet
(common) |
black
red
blue
yellow |
GB/T5574-94 |
Hardness:low middle high
Pressure:1.6Mpa～6.0Mpa
The allowed tem perature:min -35℃ max +60℃
Medium:air or water
Usage:punching washer/gasket ring making gasket board/seal of the door window |
industrial rubber sheet
(acid-resisting)
(alkali-resisting) |
yellow
red
blue
green
black |
GB/T5574-94 |
Hardness:low middle high
Medium:acidity liquid alkallnity liquid
Function:acid-resisting alkali-resisting
The allowed temperature:min -35℃ max +60℃
Usage:making all kinds of gasket ring/washer bedding equipment or surface |
industrial rubber sheet
(oil-resisting) |
yellow
red
blue
green
black |
GB/T5574-94 |
Hardness:high
Medium:engine oil.gasoline.lubricating oil.transformer oil etc.
Function:oil-resisting
The allowed temperature:min -30℃ max +100℃
Usage:punching washer/gasket ring bedding surface of equipment. |
industrial rubber sheet
(heat-resisting) |
yellow
red
blue
green
black |
GB/T5574-94 |
Hardness:low middle high
Medium:steam.air.hot air.
Function:heat-resisting ageing-resisting O3-resisting
The allowed temperature:min 100℃ max 250℃
Usage:punching all kinds of gasket ring/washer/gasket/board |
industrial rubber sheet
(insulation) |
yellow
red
blue
green
black |
GB/T5574-94 |
Hardness:low middle high
Medium:steam.air.hot air.
Function:prevent electricity/static electricty
The allowed voltage:max 50000KV
The allowed temperature:min -30℃ max +120℃
Usage:This product is suitable for use in nationaldefence.electricity.oil.chemistry.
metallurgy.communication etc(spreading surface or punching oil kinds of gasket ring/washer/boards) |
industrial rubber sheet
(prevent-slip)
(shock absorption) |
white
green
black
red
yellow
(groove) |
GB/T5574-94 |
Hardness:low middle high
Medium:air.water.hot air.
The allowed temperature:min -30℃ max +150℃
Function:prevent-slip shock absorption
Usage:spreading surface(vehicle.deck of boat,computer room) |
industrial rubber sheet
(special) |
green
black
red
yellow
blue |
GB/T5574-94 |
We can produce special specifications for industrial rubber boards according to clients`requirements for example:clip cotton/metal net.clip sail cloth etc |
